Encapsulates a node in the filesystem tree read by sqfs_dir_reader_get_full_hierarchy. More...

#include <dir_reader.h>

Collaboration diagram for sqfs_tree_node_t:

Public Member Functions
SQFS_API int	sqfs_tree_node_get_path (const sqfs_tree_node_t node, char *out)
	Recursively destroy a tree of sqfs_tree_node_t nodes.

Data Fields
sqfs_tree_node_t *	parent
	Pointer to parent, NULL for the root node.

sqfs_tree_node_t *	children
	For directories, a linked list of children.

sqfs_tree_node_t *	next
	Linked list next pointer for children list.

sqfs_inode_generic_t *	inode
	Inode representing this element in the tree.

sqfs_u32	uid
	Resolved 32 bit user ID from the inode.

sqfs_u32	gid
	Resolved 32 bit group ID from the inode.

sqfs_u8	name []
	null-terminated entry name.

Detailed Description

Encapsulates a node in the filesystem tree read by sqfs_dir_reader_get_full_hierarchy.

Examples: list_files.c.

Definition at line 114 of file dir_reader.h.

Member Function Documentation

◆ sqfs_tree_node_get_path()

SQFS_API int sqfs_tree_node_get_path	(	const sqfs_tree_node_t *	node,
		char **	out
	)

Recursively destroy a tree of sqfs_tree_node_t nodes.

This function can be used to assemble an absolute path from a tree node returned by sqfs_dir_reader_get_full_hierarchy.

The function recursively walks up the tree to assemble a path string. It returns "/" for the root node and assembles paths beginning with "/" for non-root nodes. The resulting path is slash separated, but (except for the root) never ends with a slash.

While walking the node list, the function enforces various invariantes. It returns SQFS_ERROR_LINK_LOOP if the list of parent pointers is cyclical, SQFS_ERROR_CORRUPTED if any node has an empty name, or a name that contains '/' or equals ".." or ".". The function returns SQFS_ERROR_ARG_INVALID if given NULL node or the root has a name set. Additionally, the function can return overflow or allocation failures while constructing the path.

The returned string needs to be free'd with sqfs_free.

Parameters
